Tubular Sight Glass Level Gauge

All valves use a stuffing box configuration to seal the glass tube and have a ball check shutoff to prevent loss of vessel contents in case of glass failure.

Tubular sight glass level gauge.

Connections of 1 2 or 3 4 inch npt are available for attaching the valve to the vessel. Pressure ratings range from 90 psi to 600 psi depending on end finish diameter and length required p. We are tubular level gauge of level gauges such as tubular reflex transparent magnetic float and board types. Tubular gage glass flat gage glass sight glass annular edge glass mica shields gage glass washers and gage glass accessories.

Jerguson gage valve offers a complete line of brass bronze and stainless steel tubular glass gage valves for economical service. Tubular gauge glass also called tubular glass tubular sight glass and tubular boiler glass can be divided into standard size and heavy wall size according to the wall thickness the standard size tubular glass is commonly used in low pressure boiler tanks and some other low pressure instruments. Tubular liquid level water gauge glass assemblies. It is assembled with top and bottom two isolating valves with toughened borosilicate glass tube.

Tubular level gauges are used for the low pressure tanks and vessels. End finishes may be cut ground or fire polished depending on application. Tubular sight glass also called tubular gauge glass is found on the outside of a boiler or tank and it provides a simple and efficient way to view the liquid level within the structure. A basic standard tank level gauge consists of a toughened continuous section of borosilicate glass tube which is connected at both the top and bottom to an isolation valve.

Schott duran and corning pyrex tubular gage glass is offered as red line high pressure clear heavy wall clear and heavy wall red line. It fits between an upper and lower gauge glass valve which in turn is mounted on the structure. Tubular sight glass used for observing liquid and gas flow. Tubular level gauges oil tank level gauges tubular level gauges are a cost effective method of visual liquid level indication for tanks operating at low pressures.
